ATC Linear CNC Router uses a straight-line tool magazine to automatically switch cutting tools during operation, eliminating manual changes and significantly boosting productivity for demanding machining jobs.
Long-Lasting Structure: Constructed from all-steel welded components with stress-relief processing, ensuring superior stability, durability, and reliable performance under demanding industrial use.
High-Precision Motion System: Adopts Taiwan PMI linear guides together with high-grade ball screws or rack-and-pinion systems on the X, Y, and Z axes to ensure stable movement, precise machining accuracy, and repeatable results.
Powerful Spindle: Comes with a durable air-cooled or liquid-cooled spindle running at up to 24,000 RPM, designed to machine a wide variety of materials such as wood, plastic, and aluminum.
Automatic Tool Changer (ATC): Automatically exchanges tools based on the G-code instructions, helping to cut down machine idle time and labor costs. The back-mounted linear tool magazine is designed for mechanical simplicity, stable performance, and cost-effective operation.
Advanced Control System: Equipped with smart control units (such as Syntec, NC Studio, CNCSUPER), enabling functions like automatic tool length measurement and breakage monitoring, while ensuring full compatibility with CAD/CAM software such as Aspire, VCarve, and Fusion360.
Automated Tool Length Sensor: Automatically measures the length of each new tool and synchronizes the Z-axis values with the controller, ensuring accurate depth control and stable processing quality.
Workholding System: Equipped with a zoned vacuum table and strong suction pumps to keep sheets stable while cutting, providing unrestricted surface access and faster material handling compared to clamping methods.
Integrated Dust Collection & Lubrication: Comes with a high-power dust collection system for a clean workspace and an automatic lubrication system that enables simple, routine maintenance of all moving components.
| Parameters |
Specification |
| XYZ working area |
1300*2500*200mm, 4*8ft |
| Optional working area |
1500*3000*200mm, 5*10ft
2000*3000*200mm, 6*10ft
2000*4000*200mm, 6*13ft |
| Z travel height |
200mm; Z with coupler |
| Traveling Positioning Accuracy |
±0.03/300mm |
| Repositioning Positioning Accuracy |
±0.03mm |
| Lathe Structure |
Annealing heavy-duty structure |
| Guide |
Original Germany ROUST |
| Z Structure |
Original TAIWAN TBI Ball Screw transmission |
| Table |
5 zones vacuum plus aluminum T-slot table |
| Vacuum pump |
7.5KW air vacuum pump |
| Max. Speed |
35000mm/min |
| Max. Working Speed |
25000mm/min |
| Spindle Power Motor |
7.5KW water cooling ATC Spindle |
| Spindle cooling |
Industry refrigeration water chiller 5000 |
| Spindle Speed |
24000RPM |
| Cutting bits cooling |
ATC spray cutting fluid |
| Drive Mode |
Taiwan DELTA servo motors and drivers |
| Reducer |
High precision planetary reducer |
| Operating System |
CNCSUPER Fieldbus control system |
| Tool change type |
Linear type knife library |
| Magazine capacity |
6 positions ATC |
| Tool setting |
ATC tool sensor |
| Collet |
ER25 |
| Double fixing of materials |
Pressure roller |
| Material positioning |
ATC positioning device |
| Feeding auxiliary |
Roller |
| Lubrication system |
Automatic lubrication system |
| Dust cleaning system |
Dust collector,spindle cover, pipe and bracket |
| Working Voltage |
380V/50Hz/3 phases |
| Command |
G Code, *uoo, *mmg, *plt |
| Software |
TYPE3 |
| Weight |
1800KG |
INDUSTRIES
This machine is essential for sectors where precision and repeatability are non-negotiable:
Aerospace & Defense: Manufacturing high-tolerance components like aircraft fuselage parts, wing sections, and interior fittings from lightweight but tough materials.
Precision Furniture & Cabinetry: Ideal for panel furniture, modular cabinets, and "assembly-ready" parts that require perfect alignment for dowel joints and hardware.
Automotive & Motorsports: Creating detailed engine components, dashboard molds, and high-precision prototypes for vehicle body parts.
Mold & Pattern Making: Engraving complex metal and non-metal molds for industrial casting, vacuum forming, and injection molding.
Medical Equipment: Producing steady, micron-precise components for surgical robots, MRI tables, and diagnostic devices.
Signage & Advertising: Mass-producing 3D lettering, large-scale outdoor billboards, and intricate exhibition displays.
MATERIAL
Soft Metals: Aluminum, copper, brass, and titanium.
Wood & Wood Composites: Solid hardwoods/softwoods, MDF, plywood, and melamine-faced chipboard.
Industrial Plastics: Acrylic, PVC, Polycarbonate, ABS, and Teflon.
Advanced Composites: Carbon fiber, fiberglass, epoxy resin, and insulation boards.
Other Materials: Artificial marble, foam (polyurethane/EPS), and rubber.
