Steel ATC Linear CNC Router Machine For Multi Material Processing

ATC Linear CNC Router is an automated CNC machine designed with a linear-arranged tool magazine, enabling fast and automatic tool changes that reduce manual operation and improve machining efficiency.

Durable Construction: Features a heavy-gauge all-steel welded frame with professional stress relief treatment, ensuring maximum structural rigidity, stable operation and prolonged service life in the most demanding production environments.

High-Precision Motion System: Equipped with Taiwan PMI linear guide rails and premium ball screws or rack-and-pinion, X, Y, and Z axes delivering smooth motion, high accuracy, and excellent repeatability.

High-Power Spindle: The unit features a durable air-cooled or liquid-cooled spindle with a top speed of 24,000 RPM, enabling it to tackle a diverse array of materials including wood, plastics and non-ferrous metals with ease.

Automatic Tool Changer (ATC): Controlled by the G-code instructions, the replaces cutting tools enables fast and accurate tool switching to improve workflow efficiency and lower labor requirements. The back-mounted linear tool magazine is designed for durability, easy maintenance, and cost-effective manufacturing.

Advanced Control System: Intelligent controller-driven (Syntec/NC Studio/CNCSUPER) with automatic tool length compensation, tool breakage detection, and compatibility with standard CAD/CAM software (Aspire, Vcarve, Fusion360).

Automated Tool Length Sensor: Automated Tool Length Sensor: Automatically detects the length of each tool and updates the Z-axis data in the controller, ensuring precise cutting depths and consistent machining results.

Workholding System: Multi-zone vacuum worktable paired with high-power pumps for secure fixturing of sheet materials during cutting, enabling full-surface machining access and more efficient material handling than traditional clamping methods.

Integrated Dust Collection & Lubrication: Features a high-efficiency dust extraction system to maintain a clean workspace, along with automatic lubrication for convenient and consistent maintenance of moving components.

INDUSTRIES

This machine is essential for sectors where precision and repeatability are non-negotiable:
Aerospace & Defense: Manufacturing high-tolerance components like aircraft fuselage parts, wing sections, and interior fittings from lightweight but tough materials.
Precision Furniture & Cabinetry: Ideal for panel furniture, modular cabinets, and "assembly-ready" parts that require perfect alignment for dowel joints and hardware.
Automotive & Motorsports: Creating detailed engine components, dashboard molds, and high-precision prototypes for vehicle body parts.
Mold & Pattern Making: Engraving complex metal and non-metal molds for industrial casting, vacuum forming, and injection molding.
Medical Equipment: Producing steady, micron-precise components for surgical robots, MRI tables, and diagnostic devices.
Signage & Advertising: Mass-producing 3D lettering, large-scale outdoor billboards, and intricate exhibition displays.

MATERIAL
Soft Metals: Aluminum, copper, brass, and titanium.
Wood & Wood Composites: Solid hardwoods/softwoods, MDF, plywood, and melamine-faced chipboard.
Industrial Plastics: Acrylic, PVC, Polycarbonate, ABS, and Teflon.
Advanced Composites: Carbon fiber, fiberglass, epoxy resin, and insulation boards.
Other Materials: Artificial marble, foam (polyurethane/EPS), and rubber.
